MAC AFRIC 8000 lbs 12 V Heavy Duty Winch
The MAC AFRIC EWG8000U winch is smaller than its bigger counterparts but still pulls its weight when needed due to its powerful series-wound motor. Accompanied with a cable, fairlead, wired remote, and automatic screw cone making it ready to bolt up and connect to do your general pulling.
Description
Technical Specifications
Rated Line Pull: 3 620 kg (7 981 lb) @ 6 m and 2 170 kg (4 784 lb) @ 29 m
Motor Type: Series Wound
Motor Specifications: 24V: Input: 6.3kW / 8.4HP; Output: 2.7kW / 3.6HP
Gear Reduction Ratio: 184:1
Cable Length: 29 m
Cable Diameter: 8.3 mm
Mounting Bolt Pattern: 254 x 114.3 mm (10″ x 4.5″ IN); 4-M10
Mounting Dimensions: 25.2 x 11.4 mm
Drum Size (Dia x L): 63 x 223 mm (10″ x 4.5″ IN)-M10
