MAC AFRIC 6.3 kVA (5 KW) Standby Petrol Generator
A well-sized generator that can power the average South African home. Key features include the wheel design allowing for easier moverability and the fitted AVR which ensures constant voltage supply. Features accurate Sine Wave AVR.
Description
Technical Specifications
Power Output: 5 kW (6.3 kVA)
Output Voltage: 230 V (Single‑Phase) @ 50 Hz
Amperage per Phase: 22 A
Decibel Rating: 71 dB(A)
Fuel Consumption: 2.2 L/PH
Type: Petrol Powered
Tank Capacity: 22 L
Start Type: Pull Start or Electric Start
Voltage Regulator: Yes (AVR)
Oil Capacity: 1.1 L
Engine Displacement: 389 cc
Engine Model: JDP6500E
Total Running Time: 10 Hours
Specifications Notification
Generators are rated to run at 80% of their maximum output at sea‑level in a neutral climate. Altitude and temperature can reduce engine efficiency and power output.
Expert Advice
Select a generator with at least 20% more capacity than your estimated need to avoid overloading and extend the unit’s lifespan.
Specifications Description
Power Factor: 1
4‑Stroke, Air‑Cooled, Single‑Cylinder Engine
Engine Speed: 3 600 RPM
An electrician should perform a load test to ensure compatibility with your required amperage per phase.
Limitations of Use:
Do not exceed 50% of the generator’s rated load for the first-step load.
Do not exceed 75% of the generator’s rated load for the running load.
These guidelines account for natural current fluctuations during petrol combustion.
