Hellermann Tyton Non Contact Phase Rotation Tester
Hellerman Non Contact Phase Rotation Tester provides a quick and convenient way to check phase sequence without direct electrical contact. Designed for electricians and technicians, it helps identify phase rotation safely and efficiently during installation, maintenance and fault finding.
Description
Technical Specifications
Product Type: Safety Phase Rotation Detector
Detection Method: Non-contact phase detection
Functions: Open-phase detection and phase-sequence detection
Voltage Detection Range: 75–1 000 V AC
Frequency Range: 45–65 Hz
Auto-Off: 5 min without detection
Low-Battery Warning: Power LED flashes at 4.6 V ± 0.1 V or less
Correct / Forward Rotation Indication: Green rotation LEDs flash clockwise; buzzer sounds intermittently
Reversed Rotation Indication: Red rotation LEDs flash anti-clockwise; buzzer sounds continuously
Live-Phase Indication: L1, L2 and L3 “ON” illuminated
Missing Earth Line Indication: LED not illuminated
Earth Phase (Delta Connection) Indication: LED flashes
Open-Phase Indication: Corresponding LED not illuminated
Power Source: 4 × 1.5 V AA alkaline batteries
Safety Category: CAT III 1 000 V / CAT IV 600 V
